Industrial Grade W1 W2 W4 W5 German Dovetail Clamp

Description

Our Industrial Grade W1, W2, W4, W5 German Dovetail Clamps are the epitome of precision and durability, designed to meet the rigorous demands of industrial applications.

Robust Construction for Heavy – Duty Use

These clamps are built with high – quality materials, ensuring exceptional strength and longevity. The W1 model, crafted from completely zinc – coated steel, galvanized steel, or carbon steel, offers reliable performance in general industrial settings. For more corrosive environments, the W2, with its AISI 430 band and housing and plated screw, provides enhanced resistance. The W4, featuring an AISI 304 band and AISI 430 plated screw, and the W5, with all – AISI 316 construction, are ideal for applications where high – grade stainless steel is required, such as in the food, pharmaceutical, and marine industries.

Precision – Engineered for Secure Fixing

The dovetail design, inspired by traditional German engineering, offers a unique and secure locking mechanism. The angled, interlocking surfaces of the dovetail provide a large contact area, distributing the clamping force evenly. This results in a stable and reliable connection that can withstand substantial loads without slipping or loosening. Whether used for securing machinery components, holding workpieces during machining, or in piping systems, these clamps ensure a tight fit, reducing the risk of movement or displacement.

Versatile Sizing Options

Available in a wide range of sizes, our German Dovetail Clamps can accommodate various applications. From small – scale projects to large – scale industrial installations, there is a size to suit every need. The diameter range varies across the W1, W2, W4, and W5 models, covering dimensions from as small as 8 – 12 mm to as large as 240 – 262 mm, making them suitable for pipes, hoses, and other cylindrical objects of different diameters. This versatility allows for seamless integration into diverse industrial setups.

Easy Installation and Adjustment

Designed with user – friendliness in mind, these clamps are easy to install and adjust. The simple yet effective design enables quick assembly and disassembly, saving valuable time during maintenance and equipment reconfiguration. The included screws, whether hexagon or Phillips – head, are easy to tighten and loosen, and they provide precise control over the clamping force. This ease of use, combined with the clamp’s robust construction, makes them a popular choice for industrial workers who require efficient and reliable fastening solutions.

Compliance with International Standards

Our German Dovetail Clamps adhere to strict international standards, such as DIN 3017. This ensures that they meet the highest quality and safety requirements. By choosing our clamps, you can be confident in their performance and reliability, knowing that they have been tested and approved to industry – recognized benchmarks. Whether you are operating in Europe, America, Asia, or anywhere else in the world, these clamps are a trusted choice for your industrial fastening needs.

Specification	Diameter range (mm)	Mounting Torque(Nm）	Material	Surface treatment	Bandwidths(mm)	Thickness(mm)
20-32	20-32	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
25-38	25-38	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
25-40	25-40	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
30-45	30-45	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
32-50	32-50	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
38-57	38-57	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
40-60	40-60	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
44-64	44-64	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
50-70	50-70	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
64-76	64-76	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
60-80	60-80	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
70-90	70-90	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
80-100	80-100	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
90-110	90-110	Load torque ≥8Nm	304 stainless steel	Polishing process	12	0.8
