Description

Materials and craftsmanship

High-quality materials: High-quality metal materials such as stainless steel are usually selected. Stainless steel has excellent corrosion resistance and can be used in humid and chemically corroded industrial environments. It will not rust or corrode easily, ensuring the long-term service life of the clamp.

Exquisite craftsmanship: German manufacturing processes are known for their rigor and high precision. These hose clamps are precisely processed during the production process, with extremely high dimensional accuracy, ensuring that each clamp can perfectly match the hose and provide a reliable connection.

Design features

Multiple models are available: W1, W2, W4, W5 and other models are available. Different models have differences in size, clamping force, etc., which can meet the needs of different pipe diameters and usage scenarios. Whether it is a small precision equipment or a large industrial pipeline, you can find a suitable model.

Scientific structural design: The reasonable structural design can evenly apply the clamping force to avoid damage to the hose due to excessive local pressure. At the same time, the opening and closing design of the clamp is easy to operate, and can be quickly installed and disassembled to improve work efficiency.

Performance

Strong clamping force: With sufficient clamping force, the hose can be firmly fixed to prevent it from falling off or loosening under high pressure, vibration, etc., ensuring the sealing and stability of the pipeline system.
Good elasticity: The clamp has a certain elasticity. During long-term use, it can adapt to the thermal expansion and contraction of the hose, maintain a stable clamping effect, and reduce the problem of sealing failure caused by temperature changes.

Application scenarios

Wide applicability: Applicable to various industrial fields, such as machinery manufacturing, automobile manufacturing, chemical industry, food processing, etc. In these fields, it can be used to connect different types of pipelines, transport liquids or gases, etc., to meet diverse industrial needs.

Specifications	Diameter range(mm)	Mounting torque(Nm)	Material	Surface Finish	Bandwidth(mm)	Thickness(mm)
8-12	8-12	Load torque≥8Nm	304 stainless steel	Polishing Process	9	0.65
10-16	10-16	Load torque≥8Nm	304 stainless steel	Polishing Process	9	0.65
13-19	13-19	Load torque≥8Nm	304 stainless steel	Polishing Process	9	0.65
12-20	12-20	Load torque≥8Nm	304 stainless steel	Polishing Process	9	0.65
12-22	12-22	Load torque≥8Nm	304 stainless steel	Polishing Process	9	0.65
16-25	16-25	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
16-27	16-27	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
19-29	19-29	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
20-32	20-32	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
25-38	25-38	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
25-40	25-40	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
30-45	30-45	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
32-50	32-50	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
38-57	38-57	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
40-60	40-60	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
44-64	44-64	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
50-70	50-70	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
64-76	64-76	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
60-80	60-80	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
70-90	70-90	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
80-100	80-100	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
90-110	90-110	Load torque≥8Nm	304 Stainless Steel	Polishing Process	9	0.65
