USA 1/2 Inch Stainless Steel Gas Hose Clamp – Seikou Manufacturer
| Material | W1 | W2 | W4 | W5 |
| Hoopstraps | Iron galvanized | 200ss/300ss | 300ss | 316 |
| Hoop shell | Iron galvanized | 200ss/300ss | 300ss | 316 |
| Screw | Iron galvanized | Iron galvanized | 300ss | 316 |
Description
Material characteristics
Strong corrosion resistance: 201, 301, 410 and other stainless steel materials are used. These stainless steels have excellent corrosion resistance and can effectively resist the erosion of various chemical components that may be contained in the gas on the pipe, as well as the rust of moisture, oxygen and other substances in the external environment, ensuring that it will not be damaged by corrosion during long-term use and extending the service life.
High strength and durability: Stainless steel has high strength and hardness, can withstand certain external forces to pull and squeeze, and is not easy to deform or damage. The gas hose can be firmly fixed, and even if the gas pressure in the pipeline changes or is slightly vibrated by the outside world, it can maintain a stable clamping force to ensure the sealing and safety of the hose connection.
Structural design characteristics
Suitable size specifications: 1/2-inch width design, can adapt to a certain range of gas hose diameters, usually can be used for hoses with a diameter of 1/2 inch to 1-1/4 inches, providing a wider range of applications to meet the needs of different gas equipment and pipeline connections.
Good fastening performance: Generally, standard 5/16-inch hexagonal head 410 stainless steel screws are used. This screw design is easy to tighten with tools and can reach the specified installation torque (usually 35 inches-pounds), thereby achieving a reliable fastening effect, preventing the hose from loosening or falling off during use, and ensuring the safety of gas transportation.
Simple and practical design: The structure of the pipe clamp is usually simple, consisting of basic components such as stainless steel belts and screws, without complex redundant structures, which is convenient for installation and disassembly, and can ensure stable operation in various environments. At the same time, the simple design also helps to reduce material costs and production process difficulties, and improve the cost performance of the product.
Environmental adaptability characteristics
High temperature resistance: Stainless steel has a high melting point and good thermal stability. During the gas transportation process, even if it encounters a high temperature environment generated by gas combustion, or the ambient temperature changes greatly, the hose clamp can maintain its stable performance, will not soften, deform or lose clamping force due to high temperature, and ensure that the gas hose can still be reliably fixed under high temperature conditions.
Anti-vibration and weather resistance: It is suitable for various indoor and outdoor environments and can resist a certain degree of vibration and impact. Whether it is the slight vibration caused by the operation of gas equipment in a home kitchen or the larger vibration that may be encountered in industrial sites or outdoor gas pipe systems, the hose clamp can keep it tight. At the same time, it can also adapt to different climatic conditions, such as damp, cold, hot, etc., and is not easily damaged by environmental factors.
| Specification | Diameter range(mm) | Installation Torque (Nm) | Material | Surface Finish | Bandwidth (mm) | Thickness (mm) |
| 304 All Steel 14-27 | 14-27 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 18-32 | 18-32 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 21-38 | 21-38 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 21-44 | 21-44 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 27-51 | 27-51 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 33-57 | 33-57 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 40-63 | 40-63 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 46-70 | 46-70 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 52-76 | 52-76 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 59-82 | 59-82 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 65-89 | 65-89 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 72-95 | 72-95 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 78-101 | 78-101 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 84-108 | 84-108 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 91-114 | 91-114 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 105-127 | 105-127 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 118-140 | 118-140 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 130-152 | 130-152 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 141-165 | 141-165 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 155-178 | 155-178 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 175-197 | 175-197 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 194-216 | 194-216 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 213-235 | 213-235 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 232-254 | 232-254 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 251-273 | 251-273 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 270-292 | 270-292 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 289-311 | 289-311 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-100 | 0-100 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-150 | 0-150 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-200 | 0-200 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 75-235 | 75-235 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-250 | 0-250 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-300 | 0-300 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-350 | 0-350 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-400 | 0-400 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-450 | 0-450 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-500 | 0-500 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-550 | 0-550 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 304 All Steel 0-600 | 0-600 | 12Nm | 304 stainless steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 14-27 | 14.27 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 18-32 | 18-32 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 21-38 | 21-38 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 21-44 | 21-44 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 27-51 | 27-51 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 33-57 | 33-57 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 40-63 | 40-63 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 46-70 | 46-70 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 52-76 | 52-76 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 59-82 | 59-82 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 65-89 | 65-89 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 72-95 | 72-95 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 78-101 | 78-101 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 84-108 | 84-108 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 91-114 | 91-114 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 105-127 | 105-127 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 118-140 | 118-140 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 130-152 | 130-152 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 141-165 | 141-165 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 155-178 | 155-178 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 175-197 | 175-197 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 194-216 | 194-216 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 213-235 | 213-235 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 232-254 | 232-254 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 251-273 | 251-273 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 270-292 | 270-292 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 289-311 | 289-311 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-100 | 0-100 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-150 | 0-150 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-200 | 0-200 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 75-235 | 75-235 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-250 | 0-250 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-300 | 0-300 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-350 | 0-350 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-400 | 0-400 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-450 | 0-450 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-500 | 0-500 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-550 | 0-550 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 All Steel 0-600 | 0-600 | 12Nm | 201 All Steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 14-27 | 14-27 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 18-32 | 18-32 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 21-38 | 21-38 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 21-44 | 21-44 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 27-51 | 27-51 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 33-57 | 33-57 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 40-63 | 40-63 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 46-70 | 46-70 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 52-76 | 52-76 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 59-82 | 59-82 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 65-89 | 65-89 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 72-95 | 72-95 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 78-101 | 78-101 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 84-108 | 84-108 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 91-114 | 91-114 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 105-127 | 105-127 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 118-140 | 118-140 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 130-152 | 130-152 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 141-165 | 141-165 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 155-178 | 155-178 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 175-197 | 175-197 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 194-216 | 194-216 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 213-235 | 213-235 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 232-254 | 232-254 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 251-273 | 251-273 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 270-292 | 270-292 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 289-311 | 289-311 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-100 | 0-100 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-150 | 0-150 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-200 | 0-200 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 75-235 | 75-235 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-250 | 0-250 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-300 | 0-300 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-350 | 0-350 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-400 | 0-400 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-450 | 0-450 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-500 | 0-500 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-550 | 0-550 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| 201 Semi-steel 0-600 | 0-600 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
| Customizable | 1 | 12Nm | 201 Semi-steel | Polishing process | 12.7 | 0.65 |
